Cast aluminium T-sloplate

Item number: A105419

  • Outer dimensions: 200 x 200 mm
  • T-slot spacing: 50 mm
  • Suitable for bricks according to DIN 508
  • Parallelism: +/- 0.01 mm /200 mm

Category: Cast aluminum T-slot plates

Size

Price on application

There are variations of this item. Please select the variation you wish.


secure shopping
The T-slot plate is supplied with a smooth, closed underside; this means that the plate can also be sucked onto a vacuum table. To attach it to a machine table/frame, simply drill holes at a suitable point. You have the flexibility to do this yourself, or you can use our service.

Technical data:
  • Suitable for stones according to DIN 508
  • Parallelism: +/- 0.01 mm /200 mm
  • L= 200 mm
  • B= 200 mm
  • H= 20 mm
  • H1= 7.5 mm
  • H2= 8 mm
  • D= 50 mm
  • A= 10 mm
  • C= 16 mm


We reserve the right to make technical changes
